Router Table for DeWalt DW618: Fit, Sizing & Height Fix
The DEWALT DW618 fits any router table built for a Porter-Cable-style plate — 6-inch opening, 1-3/16-inch center hole — but its fixed base has no above-table height adjustment. Skip that and you’ll pull the motor out from under the table every time you change bit depth. This guide covers which tables fit, the exact base specs, and two real fixes for height adjustment.
Does the DEWALT DW618 Have Above-Table Height Adjustment?
No. The DW618’s stock fixed base has no keyhole or above-table mechanism — DeWalt built the micro-fine depth ring for handheld use, and once the router is bolted under a table, that ring faces down and away from you. RouterForums and LumberJocks threads on this exact router confirm the same workaround owners have used for years: reach under the table, or pull the motor out of the base, turn the ring, and reinstall it.
Two ways around it. First, buy a table whose plate is drilled for above-table access on routers that support it — that helps only if you eventually swap to a router with a key-adjustable base, since the DW618 itself still lacks the mechanism. Second, an aftermarket router lift (see the O’SKOOL and similar lifts sold for Bosch-plate tables) can hold the DW618 and add crank-style height adjustment from above, though you’re paying $150–$400 for that convenience.
As one longtime RouterForums member summed it up when discussing the DW618’s fixed base: you simply can’t reach a key from above the table, so adjustment happens by hand from underneath — the same way owners have adjusted these bases in shop-built tables for over a decade.
Best DW618-Compatible Router Table Pick
Bosch RA1181 Benchtop Router Table – $200.69
Bosch specifically lists the DW616/DW618 fixed base as compatible on this table’s mounting plate — matching the plate/lift compatibility this guide covers above.
- Best for: DW618 owners who want a documented, drop-in fit
- Why we picked it: Bosch’s own compatible-router list names the DW618 fixed base by name
- Main drawback: Like the DW618 itself, still no above-table height key — you’ll use the motor-removal method or an aftermarket lift
Compare more DW618 router table options
 Option 1 Bosch RA1171 Cabinet-Style Table – $255.99
|
 Option 2 VEVOR Benchtop Router Table – $131.90
|
 Option 3 Universal Table with Steel Stand – $55.99
|
As an Amazon Associate we earn from qualifying purchases.
DEWALT DW618 Router Table Base Specs
If you’re cutting your own insert plate or ordering one, the DW618’s fixed and plunge bases both use a 6-inch round sub-base with a 1-3/16-inch center opening. The base also has a 1-3/8-inch stepped hole that’s fully compatible with Porter-Cable-style template guide bushings, including the PC 42000 bushing set most hardware stores carry. That’s the same bushing standard the Bosch RA1181 and RA1171 tables below are drilled for.
Which Router Tables Fit the DEWALT DW618?
Any table built around a Porter-Cable-style plate will physically accept the DW618 fixed base — the base’s bushing hole and bolt spacing match that standard. Bosch confirms this directly: its own compatible-router list for the RA1181 and RA1171 router tables names the DW616 and DW618 fixed base specifically, which is why both appear in the picks below. Generic PC-style benchtop tables from other brands should also fit, but unlike Bosch’s documented list, you’re matching hole patterns yourself rather than relying on a published fit.
Building Your Own DEWALT DW618 Router Table
A shop-built table costs less than most benchtop kits if you already have plywood scraps and a straightedge. Cut the insert opening to the DW618’s 6-inch base with a 1-3/16-inch center bore, and drill the bolt pattern to match the base plate holes exactly — off by even 1/8 inch and the plate will bind.
Choosing the Top Material
MDF or cabinet-grade plywood works for most home shops; both stay flat and are easy to machine. Baltic birch plywood costs more but resists sagging over years of clamping and edge-jointing pressure better than standard MDF.
Mounting and Aligning the Fence
Set the fence parallel to the miter slot (if the table has one) and as close to the bit as the cut allows — that reduces tear-out and gives the workpiece more support right at the cutting edge. Check alignment with a combination square before the first cut, not after.
Wiring and Safety
Run the switch on its own circuit rated at least 15 amps, since the DW618 alone draws 12 amps at full load. Keep the power cord clear of the router’s swing radius under the table, and always disconnect power before reaching under the table to adjust height — the fix for the missing above-table adjustment described earlier still means your hand is inches from a spinning bit if the router is live.
FAQ: Router Table for DEWALT DW618
Can you use any router table with the DEWALT DW618?
No. The table’s insert plate has to match the DW618’s 6-inch base and 1-3/16-inch center bore, plus its 1-3/8-inch Porter-Cable-style bushing hole. Tables built for that standard, like the Bosch RA1181 and RA1171, fit; tables drilled only for other brands’ bolt patterns won’t line up without redrilling.
Does the DW618 have above-table height adjustment?
No. The stock fixed base has no key access from above the table. You adjust it by reaching underneath, or by removing the motor to turn the depth ring, unless you add an aftermarket router lift built for that purpose.
What size is the DW618 router base plate?
Both the fixed and plunge bases use a 6-inch round sub-base with a 1-3/16-inch center opening and a 1-3/8-inch stepped hole for Porter-Cable-style template guide bushings, including the common PC 42000 bushing set.
Is the DEWALT DW618 discontinued?
Yes, DeWalt no longer manufactures the DW618 as a standalone unit, though it’s still sold through combo kits like the DW618PK and DW618PKB and remains common secondhand. Existing units keep working in any table built for the standard base described above.
Can any router be used with a DW618-specific router table?
No. A plate drilled specifically for the DW618’s bolt pattern won’t necessarily accept a different router’s base, since bolt spacing and bushing-hole depth vary by brand and model. Check your router’s own base diameter and bolt pattern before assuming a DW618-fit plate will work.
Conclusion
The DEWALT DW618 works in any table drilled for a Porter-Cable-style plate, and the Bosch RA1181 and RA1171 are the only tables that name it directly as a compatible fit. The one real limitation is height adjustment: without a key from above, you’re reaching under the table or adding a router lift. Confirm your table’s plate matches the DW618’s 6-inch base and 1-3/16-inch bore before you buy, and the rest of the setup is straightforward.
